|#1 - Cutting jig (and hillside template)|
To make the boards modular, anywhere hills go from board to board either on the center of an edge or on a corner need to be standard. To achieve this I have a few cardboard templates that I use to scribe the edge profiles on the sides of other pieces when building up hills. I have a "center side" template, a corner template, and a river cutout template (also to be centered on a panel). [Templates are shown in picture 2, and the use of one shown in picture 1]
|#2 - Cutting templates and planning tiles|
Panels can be anything you desire, simple or fancy, as long as they have standard joins on the sides to make them compatible with other boards. Strictly speaking, this isn't even true, as some of the boards in the collection can be non-modular but therefore only usable in certain ways. Standard size building blocks can also be combined into larger pieces (for example, 22.5" by 45", or 22.5" by 67.5"), although as you make larger pieces you create the storage issue I was trying to minimize. In addition to the standard pieces I have made thus far I am working on a "2 block" high hill and a "3 block" river section, using layers of poured Envirotex as the water. Picture #3 shows a basic panel as bought and a finished panel with a simple hill using a center edge join.
|#3 - 2' by 2' pink board and finished product|
To date I have completed ten pieces, which can be seen in picture #4 stacked in the rack I built (with their end profiles showing to see how they join). Picture 2 also shows some little template pictures I made so that I can play around with table configurations in small scale rather than pulling out all the life sized pieces and moving them around. Each piece is numbered to its matching card. Once I decide on what I want my table to look like for a game, all I have to do is see which tiles I used and pull only what I need out of the rack.
|#4 - Edge profiles, and numbered|
I will take a picture soon using some of the tiles I have made.
